BNO055 Intelligent 9-Axis Attitude Sensor Module (Accelerometer + Gyroscope + Magnetometer)
The BNO055 Intelligent 9-Axis Attitude Sensor Module is a powerful all-in-one motion tracking solution designed for robotics, drones, IoT, and embedded systems. Unlike traditional sensors, this module includes an on-board ARM Cortex processor, which performs sensor fusion internally — saving your microcontroller processing power.
This makes it ideal for Arduino, Raspberry Pi, ESP32, and STM32 projects, especially for Bangladeshi students and engineers who want accurate orientation tracking without complex coding.
With built-in accelerometer, gyroscope, and magnetometer, the BNO055 can directly output:
- Absolute orientation (Euler angles / Quaternions)
- Linear acceleration
- Gravity vector
No need for external sensor fusion algorithms — just plug and play.
Features:
- ✅ Built-in 9-axis sensor fusion (Bosch BNO055 chip)
- ✅ Onboard ARM Cortex-M0 processor
- ✅ Outputs Euler angles, Quaternion, Gravity Vector
- ✅ Supports I2C & UART communication
- ✅ Plug & play – no complex coding required
- ✅ High accuracy for motion tracking & orientation detection
- ✅ Low power consumption
- ✅ Ideal for robotics, drones, VR, IoT projects
Specifications:
| Parameter | Details |
|---|---|
| Sensor Type | 9-axis IMU |
| Chipset | Bosch BNO055 |
| Accelerometer | 3-axis |
| Gyroscope | 3-axis |
| Magnetometer | 3-axis |
| Communication | I2C / UART |
| Operating Voltage | 3.3V – 5V |
| Output Data | Euler Angles, Quaternion |
| Interface Level | 3.3V logic |
| Size | Compact module |
🔷 Use Cases:
- 🤖 Robotics projects (Line follower, humanoid robots)
- 🚁 Drone stabilization systems
- 🧭 Compass and navigation systems
- 🎮 VR / AR motion tracking
- 📱 Smart wearable devices
- 🏫 University final year projects in Bangladesh
- 🧪 Research & prototyping
